5-7 High-temperature Sn-Pb Series Solder Alloy Specification
ZhongYa (Tianjin) Company provides for all kinds of consumers several series (including 40 types) Sn-Pb solder alloys in the forms of wire, bar, foil tape. The corresponding melting point is in the range of 268℃-316℃.
5-7 High-temperature Sn-Pb Series Solder Alloy Specification
| Series | Series，℃ | Liquidus，℃ |
Electivity， Ω·m㎡/m | Products status | |
| Wire | Bar | ||||
| GHL-268 | 268 | 301 | 0.198 | Ф1.0-3.0mm | △ |
| GHL-300 | 300 | 314 | — | — | △ |
| GHL-316 | 316 | 322 | — | — | △ |
| GHL-296 | 296 | 301 | — | Ф1.0-3.0mm | △ |
Note: ※ means lead-free solder, △ represents the available products, and – stands for unsupplied products
